Role-Based Access Control (RBAC) in Kavach

🔐 Understanding Kavach's hierarchical RBAC system for fine-grained access control.

Overview

Kavach implements a hierarchical Role-Based Access Control (RBAC) system using Casbin to provide granular access control across organizations, secret groups, environments, and their associated resources. This system ensures that users can only access and modify resources they have explicit permissions for.

Key Concepts

Hierarchical Resources: Permissions cascade down the resource hierarchy
Four Core Roles: Owner, Admin, Editor, and Viewer with distinct capabilities
Implicit Ownership: Resource creators automatically become owners
Explicit Role Assignment: Only Admin, Editor, and Viewer roles can be explicitly granted
Action-Based Permissions: Different actions require different minimum role levels

Resource Hierarchy

Kavach follows a strict hierarchical structure where permissions cascade from parent to child resources:

Organizations
├── Secret Groups
│   ├── Environments
│   │   ├── Secrets
│   │   └── Providers
└── User Groups

Resource Types and Permissions

Resource Type	Permission Level	Description
Organizations	Organization	Top-level resource that contains all other resources
Secret Groups	Organization, SecretGroup	Logical grouping of related secrets and environments
Environments	Organization, SecretGroup, Environment	Specific deployment environments (dev, staging, prod)
Secrets	Organization, SecretGroup, Environment	Individual secret values (inherits from Environment)
Providers	Organization, SecretGroup, Environment	External service integrations (inherits from Environment)
User Groups	Organization	Collections of users with shared permissions

Important: Permissions cannot be granted directly on Secrets or Providers. Access to these resources is controlled through their parent resources (Environment, SecretGroup, or Organization). User Groups are organizational resources used for grouping users when granting permissions.

Core Roles

Kavach defines four distinct roles with specific capabilities and limitations:

1. Owner Role

Default Assignment: Automatically assigned to the creator of any resource.

Characteristics:

✅ Full Control: Complete access to all actions on the resource
✅ Resource Deletion: Can delete the resource they created
✅ Permission Management: Can grant/revoke permissions to other users
✅ Child Resource Management: Full control over all child resources
❌ Explicit Assignment: Cannot be explicitly granted to other users
❌ Transfer: Cannot transfer ownership to another user

Use Cases:

Resource creators who need complete control
System administrators managing critical resources
Initial setup and configuration

2. Admin Role

Explicit Assignment: Can be explicitly granted to users or groups.

Characteristics:

✅ Grant/Revoke Permissions: Can assign roles to other users
✅ Full Resource Access: Read, write, create, update operations
✅ Child Resource Management: Can manage all child resources
✅ Provider Configuration: Can manage provider configurations
❌ Resource Deletion: Cannot delete resources they have been granted access to
❌ Ownership Transfer: Cannot transfer ownership

Use Cases:

Team leads managing their team's resources
DevOps engineers managing infrastructure
Security administrators

3. Editor Role

Explicit Assignment: Can be explicitly granted to users or groups.

Characteristics:

✅ Read/Write Access: Can read and modify existing resources
✅ Resource Updates: Can update the resources they have access to (org, secret group, environment)
✅ Child Resource Creation: Can create new child resources
✅ Secret Management: Can create, update, and delete secrets
✅ Provider Sync: Can sync secrets to external providers
❌ Permission Management: Cannot grant/revoke permissions
❌ Provider Configuration: Cannot create, update, or delete provider configurations

Use Cases:

Developers managing application secrets
CI/CD pipelines requiring secret access
Application deployment processes

4. Viewer Role

Explicit Assignment: Can be explicitly granted to users or groups.

Characteristics:

✅ Read-Only Access: Can view resources and their metadata
✅ Secret Reading: Can read secret values (but not modify)
❌ Provider Access: Cannot view provider configurations
❌ Modifications: Cannot create, update, or delete resources
❌ Permission Management: Cannot manage permissions

Use Cases:

Security teams reviewing configurations
Support teams troubleshooting issues
Read-only monitoring systems

Permission Matrix

Organization Level Actions

Action	Owner	Admin	Editor	Viewer
Create Secret Group	✅	✅	✅	❌
Create User Group	✅	✅	❌	❌
Delete Organization	✅	❌	❌	❌
Grant Permissions	✅	✅	❌	❌
View Organization	✅	✅	✅	✅
Update Organization	✅	✅	✅	❌

Secret Group Level Actions

Action	Owner	Admin	Editor	Viewer
Create Environment	✅	✅	✅	❌
Delete Secret Group	✅	❌	❌	❌
Grant Permissions	✅	✅	❌	❌
View Secret Group	✅	✅	✅	✅
Update Secret Group	✅	✅	✅	❌

Environment Level Actions

Action	Owner	Admin	Editor	Viewer
Create Secret	✅	✅	✅	❌
Create Provider	✅	✅	✅	❌
Delete Environment	✅	❌	❌	❌
Grant Permissions	✅	✅	❌	❌
View Environment	✅	✅	✅	✅
Update Environment	✅	✅	✅	❌

Secret Level Actions

Action	Owner	Admin	Editor	Viewer
Create Secret	✅	✅	✅	❌
Read Secret	✅	✅	✅	✅
Update Secret	✅	✅	✅	❌
Delete Secret	✅	✅	✅	❌
Sync Secret	✅	✅	✅	❌

Provider Level Actions

Action	Owner	Admin	Editor	Viewer
View Provider Config	✅	✅	✅	❌
Create Provider	✅	✅	❌	❌
Update Provider	✅	✅	❌	❌
Delete Provider	✅	✅	❌	❌

Hierarchical Permission Inheritance

Permission Cascading

Permissions granted at higher levels automatically cascade to all child resources:

Organization (Admin)
├── Secret Group (inherits Admin)
│   ├── Environment (inherits Admin)
│   │   ├── Secrets (inherits Admin)
│   │   └── Providers (inherits Admin)
└── User Groups (inherits Admin)

Example Scenarios

Scenario 1: Organization-Level Admin

User: alice@company.com
Role: Admin
Resource: Organization (my-company)

Result: Alice can:

Manage all secret groups in the organization
Create and manage user groups
Create new environments in any secret group
Manage all secrets and providers
Grant permissions to other users at any level
Cannot delete the organization

Scenario 2: Secret Group-Level Editor

User: bob@company.com
Role: Editor
Resource: Secret Group (prod-apps)

Result: Bob can:

Create environments within the prod-apps secret group
Manage secrets and providers in those environments
Sync secrets to external providers
Cannot grant permissions to other users
Cannot delete the secret group

Scenario 3: Environment-Level Viewer

User: charlie@company.com
Role: Viewer
Resource: Environment (staging)

Result: Charlie can:

View all secrets in the staging environment
Cannot view provider configurations
Cannot modify any resources
Cannot access other environments

Role Assignment Rules

Explicit Role Assignment

Only three roles can be explicitly assigned:

Admin: Can be granted by Owner or Admin
Editor: Can be granted by Owner or Admin
Viewer: Can be granted by Owner or Admin

Implicit Role Assignment

Owner: Automatically assigned to resource creator
Cannot be explicitly granted or transferred
Recorded in role bindings with resource type and ID

Role Assignment Hierarchy

Owner (implicit)
├── Admin (explicit)
│   ├── Editor (explicit)
│   └── Viewer (explicit)
└── Editor (explicit)
    └── Viewer (explicit)

Access Control Implementation

Casbin Hierarchical RBAC Model

Kavach uses Casbin's hierarchical RBAC model with SQLx adapter for persistent storage and structured resource naming with grouped policies.

Policy Model Configuration

[request_definition]
r = sub, obj, act

[policy_definition]
p = sub, obj, act

[role_definition]
g = _, _, _

[policy_effect]
e = some(where (p.eft == allow))

[matchers]
m = g(r.sub, p.sub, r.obj) && r.obj == p.obj && r.act == p.act

Storage Configuration

Kavach uses Casbin with SQLx adapter for persistent policy storage:

// Casbin with SQLx adapter configuration
adapter, err := sqlxadapter.NewAdapter(driverName, dataSourceName, tableName)
if err != nil {
    log.Fatal(err)
}

enforcer, err := casbin.NewEnforcer(modelPath, adapter)
if err != nil {
    log.Fatal(err)
}

Database Schema:

-- Casbin policy table
CREATE TABLE casbin_rule (
    id SERIAL PRIMARY KEY,
    ptype VARCHAR(10),
    v0 VARCHAR(256),
    v1 VARCHAR(256),
    v2 VARCHAR(256),
    v3 VARCHAR(256),
    v4 VARCHAR(256),
    v5 VARCHAR(256)
);

Resource Hierarchy Structure

Kavach uses hierarchical resource naming following this pattern:

Organizations:     /organizations/{org-id}
Secret Groups:     /organizations/{org-id}/secret-groups/{secret-group-id}
Environments:      /organizations/{org-id}/secret-groups/{secret-group-id}/environments/{env-id}
User Groups:       /organizations/{org-id}/user-groups/{user-group-id}

Example Resource IDs:

org:        /organizations/1k3o131
secretgroup: /organizations/1k3o131/secret-groups/i3i3p13
environment: /organizations/1k3o131/secret-groups/i3i3p13/environments/103031
usergroup:   /organizations/1k3o131/user-groups/170101

Policy Structure

Kavach uses grouped policies for better organization and management:

1. Role-Based Policies (Grouped)

# Admin role policies
admin, read
admin, write
admin, create
admin, delete
admin, grant

# Editor role policies
editor, read
editor, write
editor, create

# Viewer role policies
viewer, read

2. User-Role Assignments

# Direct user-role assignments
user:13018310, admin, /organizations/3038013031
user:38010, editor, /organizations/319311/secret-groups/1391ene191
user:charlie@company.com, viewer, /organizations/1k3o131/secret-groups/i3i3p13/environments/103031

3. Group-to-Role Mapping Policies

# Resource bindings to group
group:10303013, admin, /organizations/31u313193/ju39u1313
group:011804104, editor, /organizations/1k3o131/secret-groups/i3i3p13
group:3u01, viewer, /organizations/1k3o131/secret-groups/i3i3p13/environments/103031
group:dev-team, admin, /organizations/1k3o131
group:qa-team, editor, /organizations/1k3o131/secret-groups/i3i3p13
group:monitoring, viewer, /organizations/1k3o131/secret-groups/i3i3p13/environments/103031

4. User-Group Mappings

# User to group mappings (when adding members to group)
user:21031031, group:011804104
user:j314h14, group:3u01
user:alice@company.com, group:dev-team
user:bob@company.com, group:qa-team
user:charlie@company.com, group:monitoring

Explanation:

group:10303013, admin, /organizations/31u313193/ju39u1313 - Group gets admin role at specified resource
user:21031031, group:011804104 - User is added as member to group, inheriting group's permissions
When a user is added to a group, they automatically inherit all permissions granted to that group

Policy Examples

Organization-Level Access

# Organization owner
user:admin@company.com, admin, /organizations/1k3o131

# Organization admin
user:devops@company.com, admin, /organizations/1k3o131

# Organization editor
user:developer@company.com, editor, /organizations/1k3o131

# Organization viewer
user:viewer@company.com, viewer, /organizations/1k3o131

Secret Group-Level Access

# Secret group admin
user:team-lead@company.com, admin, /organizations/1k3o131/secret-groups/i3i3p13

# Secret group editor
user:developer@company.com, editor, /organizations/1k3o131/secret-groups/i3i3p13

# Secret group viewer
user:monitor@company.com, viewer, /organizations/1k3o131/secret-groups/i3i3p13

Environment-Level Access

# Environment admin
user:devops@company.com, admin, /organizations/1k3o131/secret-groups/i3i3p13/environments/103031

# Environment editor
user:deploy@company.com, editor, /organizations/1k3o131/secret-groups/i3i3p13/environments/103031

# Environment viewer
user:monitor@company.com, viewer, /organizations/1k3o131/secret-groups/i3i3p13/environments/103031

User Group Management

# User group admin
user:hr@company.com, admin, /organizations/1k3o131/user-groups/170101

# User group member assignment
user:john@company.com, group:170101, /organizations/1k3o131

Group-to-Role Mapping Examples

# Complete group-to-role mapping example
# 1. User to group mappings (adding members to groups)
user:alice@company.com, group:dev-team
user:bob@company.com, group:dev-team
user:charlie@company.com, group:qa-team
user:diana@company.com, group:monitoring

# 2. Resource bindings to group (group role assignments)
group:dev-team, admin, /organizations/1k3o131
group:qa-team, editor, /organizations/1k3o131/secret-groups/i3i3p13
group:monitoring, viewer, /organizations/1k3o131/secret-groups/i3i3p13/environments/103031

# Result: Effective permissions
# alice@company.com: admin at /organizations/1k3o131 (inherits from dev-team)
# bob@company.com: admin at /organizations/1k3o131 (inherits from dev-team)
# charlie@company.com: editor at /organizations/1k3o131/secret-groups/i3i3p13 (inherits from qa-team)
# diana@company.com: viewer at /organizations/1k3o131/secret-groups/i3i3p13/environments/103031 (inherits from monitoring)

Hierarchical Permission Inheritance

The hierarchical structure allows permissions to cascade down:

# Organization-level admin cascades to all child resources
user:admin@company.com, admin, /organizations/1k3o131

# This automatically grants access to:
# - /organizations/1k3o131/secret-groups/i3i3p13
# - /organizations/1k3o131/secret-groups/i3i3p13/environments/103031
# - /organizations/1k3o131/user-groups/170101

Policy Enforcement

When a user requests access to a resource:

Resource Resolution: System resolves the full hierarchical path
Permission Check: Casbin checks policies for the exact resource path
Hierarchical Check: If not found, checks parent resources up the hierarchy
Role Resolution: Resolves user roles and group memberships
Action Validation: Validates the requested action against role permissions

Example Request:

User: developer@company.com
Resource: /organizations/1k3o131/secret-groups/i3i3p13/environments/103031
Action: read

Policy Check Order:

Check exact resource: /organizations/1k3o131/secret-groups/i3i3p13/environments/103031
Check parent: /organizations/1k3o131/secret-groups/i3i3p13
Check parent: /organizations/1k3o131
Check user groups and roles

Policy Storage with SQLx Adapter

Database Storage

Policies are stored in the database using Casbin's SQLx adapter:

-- Example policy records in casbin_rule table
INSERT INTO casbin_rule (ptype, v0, v1, v2) VALUES
('p', 'user:alice@company.com', '/organizations/1k3o131', 'read'),
('p', 'user:alice@company.com', '/organizations/1k3o131', 'write'),
('g', 'user:alice@company.com', 'admin', '/organizations/1k3o131'),
('g', 'user:bob@company.com', 'group:dev-team', '/organizations/1k3o131'),
('g', 'group:dev-team', 'admin', '/organizations/1k3o131');

Policy Management Operations

// Add policy
enforcer.AddPolicy("user:alice@company.com", "/organizations/1k3o131", "read")

// Add role assignment
enforcer.AddGroupingPolicy("user:alice@company.com", "admin", "/organizations/1k3o131")

// Add user to group
enforcer.AddGroupingPolicy("user:bob@company.com", "group:dev-team", "/organizations/1k3o131")

// Add group role assignment
enforcer.AddGroupingPolicy("group:dev-team", "admin", "/organizations/1k3o131")

// Check permission
enforcer.Enforce("user:alice@company.com", "/organizations/1k3o131", "read")

Performance Considerations

Caching: Casbin caches policies in memory for fast access
Auto-save: Policies are automatically persisted to database
Batch Operations: Multiple policy changes can be batched for efficiency
Connection Pooling: SQLx adapter supports connection pooling for better performance

Special Actions and Permissions

Secret Synchronization

Action: sync Minimum Role: Editor Scope: Secret level

Users with Editor role or higher can sync secrets to external providers using the methods exposed by providers in the secret service:

Azure Key Vault
Google Cloud Secret Manager
GitHub Actions Secrets

Note: Sync operations are performed at the secret level, not the provider level. The secret service uses provider methods to handle the actual synchronization.

Provider Configuration Management

Action	Minimum Role	Description
View Provider Config	Editor	View provider configuration details
Create Provider	Admin	Create new provider configurations
Update Provider	Admin	Modify existing provider configurations
Delete Provider	Admin	Remove provider configurations

User Group Management

Resource: User Groups Permission Level: Organization Actions:

Create user groups (Admin/Owner at org level)
Manage user group membership (Admin/Owner at org level)
View user groups (Viewer+ at org level)

Note: User Groups are not resources that can have permissions granted on them. They are organizational tools used to group users when granting permissions to other resources (Secret Groups, Environments, etc.).

Best Practices

1. Principle of Least Privilege

Start with Viewer role and escalate as needed
Grant permissions at the lowest possible level
Regularly review permissions

2. Role Assignment Strategy

# Recommended role assignments
Organization:
  - Owner: System administrators
  - Admin: DevOps leads, security team, user group managers

Secret Groups:
  - Admin: Team leads, project managers
  - Editor: Developers, CI/CD systems

Environments:
  - Editor: Application deployment processes
  - Viewer: Monitoring systems, auditors

User Groups:
  - Admin: HR, team leads (for managing group membership)
  - Viewer: Security teams (for reviewing group assignments)

3. Security Considerations

Secret Rotation: Only Editors and above can rotate secrets
Provider Access: Admin role required for provider configuration changes
Activity Logging: All permission changes are logged (audit logs coming soon!)
Resource Isolation: Use secret groups to isolate different projects/teams

4. Permission Review

Regular permission audits should include:

Review of explicit role assignments
Verification of inherited permissions
Removal of unused permissions
Validation of least-privilege principle

Troubleshooting

Common Permission Issues

1. "Access Denied" Errors

Cause: User lacks required role for the action Solution: Grant appropriate role at the correct resource level

🔮 Coming Soon: Enhanced Audit & Compliance

We're actively working on implementing comprehensive audit logging and compliance features to make Kavach even more enterprise-ready:

🔍 Comprehensive Audit Logs: Track every permission change, access attempt, and resource modification with detailed metadata
📊 Compliance Reporting: Built-in reports for SOC2, ISO27001, and other compliance frameworks
🚨 Real-time Alerts: Get notified of suspicious activities and policy violations
📈 Permission Analytics: Visualize access patterns and security metrics
📋 Audit Trail: Complete history of all RBAC changes and access attempts

Stay tuned for these powerful features that will make Kavach the most comprehensive and compliant secret management platform available!

Support and Resources

Documentation: CLI Overview
Authentication: CLI Authentication
Examples: GitHub Repository
Community: GitHub Discussions

Overview​

Key Concepts​

Resource Hierarchy​

Resource Types and Permissions​

Core Roles​

1. Owner Role​

2. Admin Role​

3. Editor Role​

4. Viewer Role​

Permission Matrix​

Organization Level Actions​

Secret Group Level Actions​

Environment Level Actions​

Secret Level Actions​

Provider Level Actions​

Hierarchical Permission Inheritance​

Permission Cascading​

Example Scenarios​

Scenario 1: Organization-Level Admin​

Scenario 2: Secret Group-Level Editor​

Scenario 3: Environment-Level Viewer​

Role Assignment Rules​

Explicit Role Assignment​

Implicit Role Assignment​

Role Assignment Hierarchy​

Access Control Implementation​

Casbin Hierarchical RBAC Model​

Policy Model Configuration​

Storage Configuration​

Resource Hierarchy Structure​

Policy Structure​

1. Role-Based Policies (Grouped)​

2. User-Role Assignments​

3. Group-to-Role Mapping Policies​

4. User-Group Mappings​

Policy Examples​

Organization-Level Access​

Secret Group-Level Access​

Environment-Level Access​

User Group Management​

Group-to-Role Mapping Examples​

Hierarchical Permission Inheritance​

Policy Enforcement​

Policy Storage with SQLx Adapter​

Database Storage​

Policy Management Operations​

Performance Considerations​

Special Actions and Permissions​

Secret Synchronization​

Provider Configuration Management​

User Group Management​

Best Practices​

1. Principle of Least Privilege​

2. Role Assignment Strategy​

3. Security Considerations​

4. Permission Review​

Troubleshooting​

Common Permission Issues​

1. "Access Denied" Errors​

🔮 Coming Soon: Enhanced Audit & Compliance​

Support and Resources​

Overview

Key Concepts

Resource Hierarchy

Resource Types and Permissions

Core Roles

1. Owner Role

2. Admin Role

3. Editor Role

4. Viewer Role

Permission Matrix

Organization Level Actions

Secret Group Level Actions

Environment Level Actions

Secret Level Actions

Provider Level Actions

Hierarchical Permission Inheritance

Permission Cascading

Example Scenarios

Scenario 1: Organization-Level Admin

Scenario 2: Secret Group-Level Editor

Scenario 3: Environment-Level Viewer

Role Assignment Rules

Explicit Role Assignment

Implicit Role Assignment

Role Assignment Hierarchy

Access Control Implementation

Casbin Hierarchical RBAC Model

Policy Model Configuration

Storage Configuration

Resource Hierarchy Structure

Policy Structure

1. Role-Based Policies (Grouped)

2. User-Role Assignments

3. Group-to-Role Mapping Policies

4. User-Group Mappings

Policy Examples

Organization-Level Access

Secret Group-Level Access

Environment-Level Access

User Group Management

Group-to-Role Mapping Examples

Hierarchical Permission Inheritance

Policy Enforcement

Policy Storage with SQLx Adapter

Database Storage

Policy Management Operations

Performance Considerations

Special Actions and Permissions

Secret Synchronization

Provider Configuration Management

User Group Management

Best Practices

1. Principle of Least Privilege

2. Role Assignment Strategy

3. Security Considerations

4. Permission Review

Troubleshooting

Common Permission Issues

1. "Access Denied" Errors

🔮 Coming Soon: Enhanced Audit & Compliance

Support and Resources
